Flood Strip Probe (F25-SSP991)
The F25-SSP991 sensor is an environmental leakage monitoring sensor manufactured by FTSV, which is used to detect occurrence of liquid leaks into the environment.
This sensor is part of the leak detection system in order to quickly and accurately detect unwanted occurrence of liquid leaks and to protect equipment located in various environments such as server rooms, data centers, offices, laboratories, residential and office buildings, industrial facilities, boilers and etc. are designed due to liquid leakage.
No need for configuration and maintenance, simple connection during installation and easy operation are the important functional advantages of this sensor. The flexibility of this sensor makes it easy to place it as desired on the floor, walls, under or around pipes, around flanges, pumps and all the desired points through glue, screws, cable clamps or any Fixed and established type of connections. It is also possible to connect several sensors of this type along with other point or rope leak sensors in series.
It is also possible to connect several sensors of point or rope type in series. This sensor is made of polyester fibers and between its textures, two stainless steel wire are used, which can be sent signal in the desired zone if it gets wet. After reduce amount of the wet, the sensor will be operational again to detect further leaks.
It should be noted that this sensor is highly efficient for use in data center and server room environments that need to cover a large number of leak sensors together and can finally provide the desired information through the detector in EMS and DCIM environmental control and monitoring systems.
Sensor Specifications
Some of the most important specifications of sensor as follow:
- Length: 25 m
- Width: 29 mm
- Sensor Material: FDY Polyester
- Wires Material: Stainless steel
- Wire Diamete : 0.5 mm
- End of Line: Close lin with 10 kΩ resistor
- How to install: place it as desired on the floor, walls, under or around pipes, around flanges, pumps and all the desired points through glue, screws, cable clamps or any Fixed and established type of connections
- Application: DCIM and BMS systems in data centers, server rooms, offices, laboratories, residential and office buildings, industrial facilities, boilers and etc
- Part number: F25-SSP991
- Related Equipments: Flood Detector P/N:FD-4-991
Flood Sensor P/N: FPO-S991
